5d 5 axis waterjet cnc machine-cnc water jet cutting machine-thick metal cutting

Quick Details

Condition: New
Place of Origin: Anhui, China (Mainland)
Brand Name: ACCURL
Model Number: ACWJ-1530, ACWJ-1530
Voltage: 380V 220V Optional
Rated Power: 7.5 KW
Dimension(L*W*H): 3880*2150*2000mm
Weight: 6500Kgs
Certification: CE ISO SGS FDA
Warranty: 3 years warranty
After-sales Service Provided: Engineers available to service machinery overseas
Plasma Power: Hypertherm
Gantry type: Table
Effective Cutting area(Length): 1500mm
Effective Cutting area(width): 3000mm
run soeed: 20m/min
Cutting positioning accuracy: ±5mm/m
Surface roughness: Ra≤25μm
CNC controller: AI, DST, DWG, DXF, DXP, LAS
Servo motor: Software Supports HPRXD and True Hole

Perfect Waterjet Cutting：

ACCURL® Water jet machining is achieved by forcing a large volume of water under high pressure through a small orifice in the cutting nozzle. The accelerated steam of water leaving the nozzle impacts the material and starts the cutting process. Kerf from the accelerated stream of water is extremely narrow. This pressure is then concentrated in a small area on the material which starts to erode the material. Softer materials can be cut with water pressure. Harder materials require the use of an abrasive feed system, such as metal cutting. The abrasive is introduced into the high pressure water stream, which then starts the erosion of the harder materials.
