cnc 3axis marble solid stone cutting engraving router machine cnc water jet machine for sale

Discount price

---

competitive price cnc 3axis marble solid stone cutting engraving router machine cnc water jet machine for sale

# Three axises adopt imported linear orbit, two line sliding track, heavy loading, stable working, high precision, longlife time.

# Whole seamless weld steel structure, not easy to distort, the table back lining is armor plate, good rigidity, the machine can bear 1 MT at least.

# Best spindle and motor, strong cutting capacity, high efficiency,Well compatibility, compatible software CAD/CAM, such as Type3, Artcam, Castmate, Wentai, CorelDraw.

# Double direction cutters cooling stem can prolong the life time of using.

# Technical features:

---

---The machine adopted 3.0kw watercooling spindle for quickly stone processing or spindle for fast cutting aluminum sheet.

---stepper motor and driver ensure that with strong power for cutting and engraving various stone.

---Advanced 3D carve budget and stable broken line enables carving professional speed and precision .Advanced file pretreatment function can correct error in the files and compatible with the process cades of multiple national and internationa software.

Discount price 3D stone CNC router technical parameters

---

Description	Parameter
X,Y,Z Working Area	1300x2500x300mm
X,Y,Z Repositioning Accuracy	±0.05mm
Table Surface	T-slot Table
Frame	Welded structure
X, Y axis transmission	Rack and Pinion gear
Z transmission	Ball Screw
Rail Configuration	20 square rail
Max. Traveling Rate	25000mm/min
Max. Working Speed	15000mm/min
Spindle Power	Water cooling 3.0KW(Opitioinal 3.0/4.5/7.5kw) spindle
Spindle Speed	24000RPM
Drive Motors	Stepper System  (Opitional Yaskawa/ Panasonic Servo motors)
Working Voltage	AC380V/50Hz/3PH
Command Language	G Code
Operating System	Mach3 System (Opitional:DSP)
Computer Interface	USB
Software Compatibility	Type3,Ucancam,Artcut (Optional )
Packing Size	Wooden case
N.W.	1300Kg/1600KG

Details of discount price 3d stone cnc router
competitive price cnc 3axis marble solid stone cutting engraving router machine cnc water jet machine for sale

Discount price 3D stone CNC router applications&samples

Field of application:

Woodworking,Advertising industry, seal industry, craft and gift, art mould, mould,furniture, furniture decoration, woodworking decoration, musical instrument, wooden handicraft .

three-dimensional wood carving in relief , and profile cutting

Applicable material:

It can be used for solid wood furniture, mahogany furniture, MDF paint door, solid wood door,

composite door, cupboard door and windows, arylic, double-color board, PVC, EVA, ABS board, stone

imitation stone, metal, Aluminum Mold ,Wood , MDF etc.

After-sale service:

1. 18 months guarantee of the whole machine.

2. Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.

3. Lifetime maintenance free of charge.

4. We will provide the consumable parts at a factory price when you need replacement.

5. Machine has been adjusted before delivery.

6. Our staff can be sent to your company to install or adjust if necessary.

Quick Details

---

Condition: New
CNC or Not: CNC
Place of Origin: Anhui, China (Mainland)
Brand Name: ACCURL
Model Number: 1325 price marble solid stone cutting engraving 3axis router machine
Voltage: 220V/380V
Power(W): 3.0KW
Dimension(L*W*H):1300*2500*300mm
Weight: 1800KG
Certification: CE ISO, CE ISO FDA
Warranty: 18 Months
After-sales Service Provided: Engineers available to service machinery overseas
Name:1325 price marble solid stone cutting engraving 3axis router machine
Control system: Mach3/DSP/Syntec/NC studio
Guide rails: Taiwan Hiwin square guide 25mm rails
Inverter: Fuling inverter/Taiwan Delta inverter
Driving mode: stepper motor and drivers
Spindle power: 2.2kw /3.0 Kw /4.5kw /5.5kw/9.0kw
Work table: T slot table with water tank
Z transmission: Taiwan TBI ball screw transmisstion
Work Dimension: 1300*2500*300mm
