Model Number:	1515L CNC Water Jet Cutting Machine	Effective Cutting Area(Length):	1500mm
Effective Cutting Area(width):	1500mm	Cutting Positioning Accuracy:	±0.5mm/m
Servo Motor:	Software Supports HPRXD And True Hole	Keywords:	Water Jet Cutter

China Accurl Brand Gem Water Jet Cutter machine for stone pattern design With High Quality

Product Description

The ACCURL® abrasive water jet machine is a high-pressure waterjet machine that utilizes straight water cutting or abrasive waterjet cutting to cut several types of material. The ACCURL® is a heavy-duty precision, ground ball screw designed system for maximum precision and rigidity. The ACCURL® is built to the most stringent standards in the machine tool industry.

The ACCURL® using the water jet high-pressure cutting process to cut material thicknesses from gauge up to 8".

The ACCURL® will cut material such as Aluminum, Armor Plate, Brass, Carpet, Copper, Glass, Granite, Leather, Marble, Mild Steel, Plastic, Stainless Steel, Stone, Tile, Titanium.

Perfect Waterjet Cutting:

ACCURL® Waterjet machining is achieved by forcing a large volume of water under high pressure through a small orifice in the cutting nozzle. The accelerated steam of water leaving the nozzle impacts the material and starts the cutting process. Kerf from the accelerated stream of water is extremely narrow. This pressure is then concentrated in a small area on the material which starts to erode the material. Softer materials can be cut with water pressure. Harder materials require the use of an abrasive feed system, such as metal cutting. The abrasive is introduced into the high pressure water stream, which then starts the erosion of the harder materials. Although waterjet machining is the slowest cutting process, there are definite advantages that outweigh its' pace:

1. No Heat-Affected Zone

2. No Mechanical Stresses

3. Very Narrow Kerf

4. Can Cut Various Materials

5. Can Process Extremely Detailed Parts

6. Minimal loss of material

7. Environmentally Friendly

Main Features

1. Can be transfer the drawing to cutting quickly

2. Quick position-some or few fixing equipments

3. Hing accuracy-reduce the recutting

4. Quicker cutting speed

5. In no need of fabrication for the working parts

6. Safer for the operator and circumstance osteam,dust,smog etc

7. Cool cutting-no heat will be prouduced

8. Clear processing,in no need of clear the working parts again

9. Good cutting finishes-in no need of trimina the cutting finishes again

10. Narrow cutting gap

11. Quick calibration and easier versatility way of cutting. It has been proved that it can be used in mass production in the ideal system

12. Fit for CAD/CAW software

13. Waterjet cutting machine can cut almost all the materials.It can cut the foilat the thickness of 200mm

System

Hp System: WJPOWER-400(Semi Imported Configuration)

Max.Pressure: 400Mpa

Max.Flowrate: 3.7L/min

Electrical Power:30KW/40HP

Voltage: 220V~480V/50,60HZ.3PH

Some Key Parts Adopt Imported Parts

Our Service

Pre-Sales Service

1.Technical solution.

2. Online video authentication machine work.

3. Cutting samples provided by DHL.

After-Sales Service

1. Supplier will provide detail manual for software, hardware

and trouble shooting, also supplier should give necessary

guidance online if Buyer need. If it’s necessary, Buyer

should send regular his technical staff to Supplier for technical training.

Detailed Images

1. Machine Frame

The MAX series features a body with electric

components built securely into the body of the machine.

This unique monoblock design allows for simple

installation and the flexibility for the system to be relocated to a multitude of locations.

2. Servo Drive & Motor

The imported servo motor (Y-axis driven by two servo motors) along with the sophisticated planetary reducer ensures steady, precise and reliable drive.

3. Ball Screw with Rotary Nut

Precision ball screws feature high reliability and repeatability that increase performance and accuracy.

4. Cutting Heads USA Hypertherm

The IDE head is a single, easy to use piece. The single cuttinghead piece consists of a body, diamond orifice, and mixing chamber. It has a 90 degree inlet that keeps abrasive from building up at the head. It has a flat seal even to the nozzle tube which eliminates risk of breaking the orifice. It is very useful for companies with multiple waterjet operators.

Specification

Model			ACCURL-4020L
working table		mm	3000 x 1500
X-axis	stroke	2000	3000
X-axis	Speed	0~15	0~15
Y-axis	stroke	1000	1500
Y-axis	Speed	0~15	0~15
Z-axis	stroke	150-180	150-180
Z-axis	Speed	0~12	0~12
Control accuracy		mm	± 0.01
Positioning accuracy		mm	± 0.02
High Pressure System	Max Pressure	380	380
High Pressure System	Power	37(50HP)	37(50HP)
Total electric power		KW	38
Max load of working table		Kgs	1000
Format supported		AI, PLT, DXF, etc
Machine weight		Kgs	5650
Outside dimension		mm	4050x2250x1850
