Applicable materials and industry
Suitable for stainless steel, carbon steel and some other metal materials precise cutting, applicable for aerospace technology, rocket, plane, robot, elevator, steamship and automobile manufacturing and metal parts processing industry for metal plate, advertisement, kitchen ware, bit tool, hardware etc.
Machine features:
1. Good beam quality: smaller focused spot, cutting lines more sophisticated, higher efficiency, better processing quality
2. Cutting speed: 2 times the same power over carbon dioxide laser cutting machine
3. Stable performance, laser life of laser sources up to 100,000 hours
4. Electro-optical conversion rate: Fiber laser cutting machine Electrical and optical conversion rate three times higher than carbon dioxide laser, energy saving
5. Low operating costs: the machine consumes about the same carbon dioxide laser cutting machine for 20-30%
6. Low maintenance costs: no need auxiliary gas, simple optical parts(only need one lens and one mirror)
7. Convenient operation and maintenance: no need to adjust the optical path, easy to learn and operate.
Basic Info
Cooling System: Water Cooling
Automatic Grade: Automatic
Type: Oscillating Mirror
Engraving Method: Vector Engraving
Specification: 3000mm*1500mm
HS Code: 8456100090
Application: Construction Industry, Metal
Technical Class: Continuous Wave Laser
Applicable Material: Metal
Laser Classification: Free Electron Laser
Origin: China
Machine Technical Parameters
| *Max. working area | 1500×3000mm |
| *Laser Power | Fiber 1000W |
| *Cutting thickness | 0.1-12mm carbon steel / 0.1-10mm stainless steel |
| *Laser wavelength | 1070nm |
| *Rated power | 10-100% |
| *Machine transmission model | Gear and Rack |
| *Line acceleration | 3000mm/s |
| *corner acceleration | 2000mm/s |
| *X,Y-axis repeat location accuracy | ±0.01mm |
| *Min. cutting line width | 0.02mm |
| *Max. cutting speed | 30m/min |
| *Max moving speed | 75m/min |
| *Machine Weight | 5500KG |
| *Machine dimension | 4.0x2.5x1.5M |
Guarantee and after sale service:
* 2 year guarantee for whole machine; 8 months for laser tube and mirrors
* 24 hours technical calling or e-mail service for any technical questions of our machine
* We offer detailed User Manual for machine installation, operation, and also for Software
