Performance Parameter
| Number | Discription | Parameter |
| 1 | X,Y Working Size | 1300X900mm |
| 2 | Laser Types | Hermetic And Detached CO2 Laser Tube |
| 3 | Laser Power | 60W,80W,100W, 130W |
| 4 | Engraving Speed | 50-50,000mm(1.97-1970inch)/min |
| 5 | Cutting Speed | 18,000mm(709.2inch)/min |
| 6 | Reposition Accuracy | 0.01mm |
| 7 | Location precision | <0.01mm |
| 8 | Minimum Letter Size | 1.5mm(0.05inch) |
| 9 | Driving system | stepper |
| 10 | Cooling mode | Water-cooling and protection system |
| 11 | Auxiliary Devices | Exhauster And Exhaust Pipe |
| 12 | Software | Lasercut 5.3 |
| 13 | Voltage | 220V(110V),50/60Hz |
| 14 | Total Power | 1100W |
| 15 | Packing Size(LXWXH) | 2000X1500X1300mm |
| 16 | G.W. | 350KG |
| 17 | Supported Image Form | BMP, CIF, JPEG, TGA, TIFF, PLT, AI, DXF, DST (TIANDAO Embroidery Software), DWG, CDR, etc |
| 18 | Optional | Up&Down work table, Digital display, Rotary Clamp, Red light pointer, Auto focus, water chiller |
Machine Introduction
The Paper Laser Cutting Machine features digital DSP control panel, HIWIN rails, the machine can be matched to AutoCAD, Corel DRAW CAD and all other graphics processing softwares for outputing original graphics. This series machines firstly use USB port data interface which supports hot-plugging and momentary data transmission to realize high efficiency without accounting computer resource. The LCD controlling panel brings friendly computer-human interface and easy operation.
Material
Advantages
1).The "front" and "back" of our laser machine can be open, suitable for super-length material process.
2).Exclusive no water warning and automatic protection system, to protect the working life of laser tube effectively. The power control system has exclusive automatic protection equipment to ensure the stability and safety of the machine to the best.
3).LCD control panel in English, convenience of operation control.
4).Import liner bearing with high engraving precision
5).offline control system which can not only work without computer, but also connect to U disk, USB communication
6).Imported metal mirrors, with good ability of reflection and focusing, long working life.
7).Red dot position system realizes the exact position without laser.
8).Auto Focus technology, realize "easy focus & high efficiency" in real, not only a word.
Applications
Advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry, Vector Cutting, Raster Engraving, Signmaking, etc.
Guarantee & After Sales Service
1.)The laser machine is guaranteed for 12 months.
2.)Technical support by phone, e-mail or MSN around the clock.
3.)Friendly English version manual and operation video CD disk.
Always here for you
Deeply rooted in our company's philosophy is customer orientation, which is achieved through the concentration of technical know-how, combination of highest quality components, integration of advanced machining techniques, persistence of technological innovation, extension of sales network and specialization of after-sale service. All around the clock, all around the world, we are always here for you.
FAQ
1.How about the delivery time?
Normal 3axis CNC machine-within 2weeks.
ATO CNC machining center-within 4weeks.
4axis CNC machine-within 50days.
5axis CNC Router-within 6months.
2.What kind of payments do you support?
T/T.L/C.other kinds pease contact with us.
3.What’s the MOQ?
For whole machine,MOQ=1.
4.Can you produce according to customers design?
Sure,we are professional manufacturer,OEM are also welcome.
5.Can you tell me your main customers?
That’s our customer’s privacy,we should protect their information.
At the same time, please rest assured that your information is also safe here.
6.Consult
We will recommend the most suitable machine to you after being informed by your requirements,such as the main jobs you wanna the machine to process,the materials you will wanna to process,the working area you want,the max cutting thickness,etc.
Quick Details
Application: Laser Cutting
Condition: New
Laser Type: Other
Applicable Material: Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Cutting Thickness: Other
Cutting Area: 1300*900mm
Cutting Speed:50-60,000(1.97-1970inch)
CNC or Not: Yes
Cooling Mode: Water Cooling
Control Software: Leetro or Ruida
Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin: Anhui, China (Mainland)
Certification: CE, ISO
After-sales Service Provided: Engineers available to service machinery overseas
Product name: sheet metal laser cutting machine price
Color: Customization(White and gray, blue and white, etc)
Size (L*W*H): 3400 x 18300 x 1300mm
Warranty: One year
OEM:YES
Driver System: LeadShine Stepper Or Fuxing Stepper
ODM:YES
CO2 Tube brand: Weegiant Or RECI
Table Type: Blade or Vacuum
Software:Laser Cut 5.3
