laser plate cutting machine

Detailed Product Description


Model Number:KJG-1530DT-1000W ACCURLWorking Range:1500x3000mm
Laser Type:USA NLIGHT Fiber YLS-1000wReduction Gears:French MOTOREDUCER
Total Power Consumption:Accurl Laser Professional Laser Cutting SoftwareKeywords:Laser Cutter

Product Introduction


Incredibly fast and fl exible, the Genius KJG fiber laser cutting system is ideal for ultra-high speed cutting of thin sheet materials. The Genius KJG has the ability to cut a wide range of ferrous and non-ferrous metals while maintaining low cost operation.

ACCURL’s fiber laser cutting machine are designed to be truly maintenance free. Driven by a reliable, rack & pinion direct-drive system with AC servo motors, this model achieves very high acceleration speeds.

• Manufactured by people who use their own machines.
• The resonator comes with a 100,000 hour warranty from the manufacturer (IPG)
• Higher cutting speeds possible
• Dual interchangeable tables allow for faster loading and unloading, reducing downtime
• Laser wavelength is one-tenth of a CO2 laser
• Reduction in cutting variables or tribal knowledge
• Fiber Laser is extremely efficient, equates to very low power consumption
• Low cost of operation, energy cost reduced, no laser gases requied to produce beam
• High cutting flexibility (Steel, Stainless Steel, Brass, Copper, Titanium, Aluminum, and more)

• Laser beam transmitted through a fiber optic.cable rather than with mirrors and channel tubing resulting in negligible power loss.

• Created and tested in a 100,000 sq ft Research and Development facility operating 9 metal cutting fiber Lasers, cutting 24/7.

MAIN FEATURES


• Excellent cutting quality for fine thickness and medium thickness sheet metals.

• Maximum simultaneous positioning speed: 160m/min.

• Acceleration speed: 14 m/ s2 (1.5G).

• Precision: + - 0.05 mm.

• Energy efficiency: greatly reduced power consumption.

• IPG Resonator. Power output from 500W to 1500w .

• RayTools cutter cutting head with power output up to 2kw.

• Precitec HP cutting head for po wer output of more than 2kw.

• Fully enclosed and cabinned to ensur e máximum operator protection.

• Effective high to low pressure gas exchange system.

• Capacitative Sensor, high pressure cutting head.

• Automatic mechanized Nesting power output control function.

• Automatic time and unit cost calculation function.

• Network connection from external.

• Smoke extraction (included in series models).

• 3 point reference sensor (sheet metal rotation detector).

• Collection of work pieces and trimmings.

• Dual proportional valve control system for different gas pressures and special system for high pressure cutting.

Main Features


• Acceleration speed: 19,6 m/s2 (2G).
• Maximum simultaneous positioning speed: 160m/min.
• Precision: + - 0.05 mm.
• Energy efficiency: greatly reduced power consumption.
• Excellent cutting quality for fine thic kness and medium thickness sheet metals.
• IPG Resonator. Power output from 1 kw to 6 kw .
• Precitec light cutter cutting head with po wer output up to 2kw.
• Precitec HP cutting head for po wer output of more than 2kw.
• Fully enclosed and cabinned to ensur e máximum operator protection.
• Effective high to low pressure gas exchange system.
• Capacitative Sensor, high pressure cutting head.
• TCI Cutting parameter tables.
• Pre-cut film protector.
• Automatic mechanized Nesting power output control function (edges, start-ups).
• Automatic time and unit cost calculation function.
• Network connection from external.
• Automatic table exchanger (included in series models).
• Smoke extraction (included in series models).
• 3 point reference sensor (sheet metal rotation detector).
• Piercing Sensor.
• Collection of work pieces and trimmings.
• Dual proportional valve control system for different gas pressures and special system for high pressure cutting.

Detailed Images


Machine Parts

Name: Machine Body

Brand: ACCURL

Original: CHINA

1. the steady gantry framework provides an open worktable.

2. Synchronous X/Y/Z axes: The Z-axis can run 150mm, suitable for cutting many varieties of metal sheets.

3. High quality guarantees its durability and easier maintenance

Conveyor System

Name: Conveyor System

Brand: ACCURL

Original: CHINA

A special hard steel construction conveyor system, standard on our machines, is located under the workspace. The conveyor removes slag and small parts during the cutting process. The operator can choose the movement direction of the conveyor.

Machine Parts

Name: HIGH PRECISION DRIVE SYSTEM

Brand: Wittenstein

Original: Germany

The Wittenstein high precision helical gear rack and pinion system uses precision planetary and servo-worm reducers. Our special design eliminates any noticeable backlash variance. The rack used in these systems is also hardened & precision ground.

Main Features

Name: SINGLE CABLE SERVO MOTOR TECHNOLOGY

Brand: YASKAWA

Original: Japan

1. Accurl has 4 servo motors for all axial movements.These are the latest technology single cable servomotors.

2. Power and process data are transmitted in onestandard motor cable, significantly reducing costs.

3. This technology also gives more accurate positioningand more geometrically accurate parts

Standard Euipment


CUTTING TABLE

The dual cutting table system is designed for in-creasing your workflow and reducing time spent on placing and removing materials. Cutting table exchange speed can be adjusted according to thickness of materials.

NOZZLE CLEANER

Keeping your machine cutting quickly and cleanly is important. Our nozzle cleaner helps improve the life of your nozzles so your cuts stay consistent, longer.

Techincal Parameter


ModelKJG-1530 / IPG 1000w
Maximum cutting capacityMild steel10mm
Stainless steel4mm
Aluminyum3mm
Copper1.5mm
Laser PowerYLR-1000Watt
Max running speed40/min
Work piece dimensions1500 x 3000mm
Rapid traverse (X and Y axis)105 m/min
Acceleration1.2G (12m/s2)
Absolute positioning accuracy± 0.03 mm
Max. load capacity1550 kg
Fume extractor1000 m3/hour
Laser Cutting HeadRayTools BM110 from Switzerland
Feed rateProgrammable up to 30 m/min.
Applied MaterialsThin mild steel, Stainless steel, Aluminum, Copper plate
