Main feature:
1. Excellent Path Quality: Smaller laser dot and high work efficiency, high quality.
2. High Cutting Speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.
3. Stable Running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;
4. High Efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.
5. Low Cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
6. Low Maintenance: fiber line transmission no need reflect lens, save maintenance cost;
7 Easy Operations: fiber line transmission, no adjustment of optical path.
Quick Details
Application: Laser Cutting
Condition: New
Laser Type: Fiber Laser
Applicable Material: Metal
Cutting Thickness: 0-6mm
Cutting Area: 1500*3000mm
Cutting Speed: 25m/min
CNC or Not: Yes
Cooling Mode: Water Cooling
Control Software: Cypcut
Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Certification: CE, ISO, SGS
After-sales Service Provided: Engineers available to service machinery overseas
Keyword: affordable laser cutter
Product name: affordable laser cutter
Machine size(l*w*h): 2.4*4.7*1.9m
Laser output power: 500W/1000W/2000W
Power allocation: 380V/220V±10%,50Hz/60
Max moving speed: 100m/min
Min line width: 0.1mm
Sheet metal cutting area: 1500x3000mm
Metal tube cutting: 3000mm
Drive system: Schneider servo motor
Technical parameters:
Max Cutting Range | 3000*1500mm | 3000mm | According to Demands |
Machine Size(L*W*H) | 2.4*4.7*1.9m | ||
Accessory Parts(L*W*H) | Chitler 1*1*1.2m Control Box 1*0.8*1.8m Fiber Module 0.5*0.6*0.14m | ||
Laser Medium | Single Core Junction Semiconductor Module | ||
Max Cutting Speed | 25m/min | ||
Cooling Way | Water Cooling | ||
Laser Power | 500W(Option 200W/300W/400W/1000W/2000W) | ||
Min Line Width | 0.1mm | ||
Cutting Depth | 0.2-6mm | ||
Driving and Transmission Way | Imported Servo Motor and Linear Guide Rail | ||
Power Requirements | 380V/50Hz/16A | ||
Continuous Working Time | 24Hours | ||
Related Weight | Gross weight 4100kg |
