metal sheet stainless steel laser cutting machine 4kw laser cutter fiber laser 4000w

Hanslaser G3015F metal sheet Stainless Steel laser cutting machine 4kw laser cutter fiber laser 4000W

Product Description

laser cutter is equipped with IPG laser generator as well as other efficient drive mechanism such as high precision gear rack, high precision linear guide rail, etc., and assembled through the advanced Han’s 701 CNC system. It is a hi-tech product integrating laser cutting, precision machinery, CNC technology, etc. mainly used to cut and form carbon steel sheets, stainless steel sheets, aluminum alloys, composite materials, etc., with the features of high speed, high precision, high efficiency, high price performance ratio, etc.

System Components

Model
Name
Qty.
Remark
G3015F
Large Power CNC Laser Cutter
1 set
HANSLASER
IPG
Laser
1 set
IPG
Standard Configuration
Autofocus Head
1 set
HANSLASER
Standard Configuration
CNC System
1 set
Han’s 701
Standard Configuration
Water Chiller
1 set
HANSLASER
Standard Configuration
Refrigerated Air Dryer
1 set
Atlas/Parker
Standard Configuration
Regulated Power Supply
1 set
HANSLASER
Standard Configuration
Programming Nesting Software
1 set
CNC KAD
Standard Configuration
Exhaust System
1 set
HANSLASER

Environmental-Friendly

Fiber Laser is using Ytterbium as the lighting materials, not necessary to use high-purity helium、nitrogen and CO2 as the consumable materials; High conversion lightning which can up to 30%-40%, the result will be low carbon and more economics.

Ultra-high speed flying cutting

G3015HF machine tool, the dynamic performance of the beam is rising. G3015HF laser cutting machine can cut 0.5mm stainless steel to 100m/min. The high efficient processing guarantee creates higher value for the user.

Cutting expert

Fiber Laser’s wavelength is 1.06μm, 1/10 compare with CO2 Laser, more easy to be absorbed by metal materials, not only higher cutting speed with cutting MS、SUS and SUS, also has fiber Laser’s wavelength is 1.06μm, 1/10 compared to CO2 Laser.

Sample

ACCURL Laser F series 6kw Cutting Demo 8MM MS
ACCURL Laser F series equipped with fiber laser from 1kw to 12kw. The excellent impulse power allows cutting machine a fast cutting speed, better stability, high precision, and a long life span during metal processing.

Quick Details

Application: Laser Cutting
Condition: New
Laser Type: Fiber Laser
Applicable Material:Metal
Cutting Thickness: 0-25mm
Cutting Area:3000mm*1500mm
Cutting Speed: 0-60000mm/min
CNC or Not: Yes
Cooling Mode: Water Cooling
Control Software: Han's PA
Graphic Format Supported: DWG, DXF
Certification: CE, ISO
After-sales Service Provided: Engineers available to service machinery overseas
Working area: All
Laser power: 4000 watt
Function: 4KW laser cutting metal
Type: fiber
