portable cnc plasma cutter cutting machines , table type programmable plasma cutter



Detailed Product Description

---

Model Number:	GSII-PS3520-PMAX-105A	Plasma Power:	Hypertherm Powermax105 USA
Gantry Type:	Table	Effective Cutting Area(Length):	3700 X 16800mm
Flame Cutting Thickness:	6-350 Mm	Cutting Positioning Accuracy:	±0.5mm/m
Track Length:	According To Customers'requirement	Keywords:	CNC Flame Cutter

China Accurl Gate CNC Plasma Flame Cut Cutter Cuting Machine 3700mm x 20800mm

Product Description

Portable cnc flame cutting machine can be programmed to cut any plane shape parts composed of beeline and arc ,which are same as large gantry cutting machines . It is equipped with a 5.7 inch LED with dynamic and static graphical display .It is directly perceived and very easy to learn .It can be programmed to cutting parts directly , and also can be operated in computer translating instructions into a program file by CAD program , and then deducing it via U hardware .The standard positioning of this machine is flame cutting ,external hanging plasma cutter is also workable .
1. Economical and Practical,especially for small and medium-sized enterprises;
2. Small volume,light weight,easy to move,no occupying fixed site;
3. Preset graphics database,can store over 1000 cutting program files;
4. Motors,drives,electromagnetic valve,and other important components,all use well-known brands at home and abroad;
5. Reserve plasma cutting function interface,support for plasma cutting;
6. Electric hoist,convenient ant quick.
7. Programmable cutting arbitrary shape parts of line and arc .
8. Dynamic and static graphic display, easy to learn.Can convert CAD file in computer, through USB flash drive transmits to machine to realize cutting all kinds' graphs and also can program and operate directly on the machine .
9. Track and movement organizations adopt unique design, ensuring the working precision of machine.
10. Can use flame cutting (gas cutting ) and plasma cutting .
11. Interfaces in English or Chinese can be converted freely.
12. Economical, Portable and easy to operate.
13. Great working stability, effective shield plasma high frequency interference.

Fatures

1. Welded lathe bed of thick-wall profiled steel, more solid and stable.
2. Reasonable lathe table design, 10 mm thickness steel plates fixed on lathe table covered by cast sheath with spikes. Steel plates will not be damaged even under raging flame. The level difference of whole double-deck platform remains in 0-1.5mm.
3. Advanced material inclined discharging design. All finished work pieces and fragments slide into both sides of tunnel for safe and convenient collection.
4. Panasonic Servo motor, high accuracy rack transmission. Low noise, stable and accurate coordinate movement.
5. Start control system made in Sino-US joint venture and design Software Type3 and Ucancam with auto material saving function.
6. American Cut-Master power supply (Power: 100A) together with high sensitive arc pressure adjuster. Self-adjusting to choose the best distance between plasma head and work piece automatically in order to ensure cutting accuracy.
7. Best choice for all kinds of different thickness material and heterotypic sheet cutting.

STANDARD COMPONENTS

1. Make up of gas decompression valve and pressure gauge.Clear to check the whole machine pressure.
2. Adopt U71 heavy-duty rail by fine machining.
3. According to user’s requirement,assemble CNC flame single torch,power-spray scribe torch,stamping unit,plasma mechanical torch or linear
triple cutting torch,and also fit auto igniter and auto height controller.
4. To ensure the beam won’t deform,it is designed in welded square structure,tempered to eliminate mechanical stress,and then processed by precision machinery.It has high mechanical strength and good rigidity.High-precision and fine-grinded guide rail,gear wheel and gear rack in high steel quality are assembled on top of the beam.Therefore,the accuracy of latcral movement can be guaranteed.The transverse track is bolted on the beam for the convenience of replacement and adjustment.
5. Used in the tracheal cable transmission of numerical control cutting torch,it can work continuously without generating mechanical fatigue.
6. To achieve synchronous motion of two supporting plate by steel strip.

Applications

This Portable cnc plasma cutting machine can cut mild steel with flame cutting, and cut high carbon steel, stainless steel,aluminum, copper and other non-ferrous metal with Plasma cutting; can configurate as you required.,thus it is widely applied in industries such as machinery, automobile, shipbuilding, petro-chemical, war industry, metallurgy, aerospace, boiler and pressure vessel, locomotive etc.
Suitable for sheet processing, do word, etc., and other advertising equipment (vacuum molding machine, engraving machine, slotting machine, etc.,) the formation of advertising word processing line. Dozens of times higher than that of traditional craft processing efficiency.

Machine instruction

Portable numerical control flame/plasma cutting machines can be programmed to cut any plane shape parts composed of beeline and arc ,which are same as large gantry cutting machines . It is equipped with a 5.7 inch LED with dynamic and static graphical display .It is directly perceived and very easy to learn .It can be programmed to cutting parts directly , and also can be operated in computer translating instructions into a program file by CAD program , and then deducing it via U hardware .The standard positioning of this machine is flame cutting ,external hanging plasma cutter is also workable .

Type	ACCURL PS - 3520
Product Name	CNC Flame Cutter
Cutting Table	3700 x 20800 mm
Machine Width	5750 min-1
Machine Lenght	22200 mm
Machine Height	2200 mm
Table Height	750 mm
Table Width	3700 mm
Table Lenght	19200 mm
X Axis Stroke	4300 mm
Y Axis Stroke	20200 mm
Weight	24000 kg
