raycus fiber laser power cnc fiber laser cutting machine 6kw compact design

Detailed Product Description

Model Number:	ECO-FIBER-1530-6KW ACCURL	Working Range:	1500x3000mm
Laser Type:	USA Raycus Fiber YLS-6Kw	Transmission:	Taiwan YYC Gear And Rack
Laser Head:	Swiss Raytools Auto-following	Table-driven System:	Japanese Yaskawa Servo Motor & Driving System
Total Power Consumption:	Accurl Laser Professional Laser Cutting Software	Keywords:	Laser Cutting Machine In Metal

6KW Laser Cutting Machine in 16 mm Aluminyum Alloys metal with Raycus Fiber Laser Power

Product Introduction

The ACCURL Fiber Lasers bring a cost effective, low-maintenance, low operating cost and environmentally friendly solution to your organization. Our fiber laser machines provide quality cutting and tolerances with minimal productivity loss between jobs, equating to a higher return on investment.

• Manufactured by people who use their own machines

• Laser beam transmitted through a fiber optic cable rather than with mirrors and channel tubing resulting in negligible power loss.

• The laser light source has a life expectancy of more than three times that of an equivalent CO2 laser.

• Higher cutting speeds possible

• Dual interchangeable tables allow for faster loading and unloading, reducing downtime

• Laser wavelength is one-tenth of a CO2 laser

• Reduction in cutting variables or tribal knowledge

• Fiber Laser is extremely efficient, equates to very low power consumption

• Low cost of operation, reduced energy cost, no laser gases required to produce beam

• High cutting flexibility (Steel, Stainless Steel, Brass, Copper, Titanium, Aluminum, and more)

• Very few consumables

STANDARD EQUIPMENT

• Stress relieved laser machine frame

• Auto-changing dual pallet system

• Light source

• Chiller

• Radan or Lantek CAD/CAM system

• Precision Rack & Pinion Drive System (Made in Germany)

• 3 lower protective lenses

• 5 Nozzles each of the Following: (1.0mm, 1.2mm,1.5mm, 2.0mm , 2.5mm , 3.0mm)

• 3 Ceramic Nozzle Adapters

• Auto-calibrated nozzle system

• Lens with 5.9” Focus Length

• Smart Slag Collection System/ Chip Conveyor

• Fiber Beam Transmission System (Fiber Cable)

• Operates with both N2 and O2 (cutting) gases

• Home Position Alignment System

• Auxiliary Gas Selector

• Auxiliary Gas Pressure NC function

• Auto Reflection Warning

• Working Lights

• Warning Indicator Lamps

• Lens Cleaning Kit

• Removal and Adjustment Tools

• Ground Plates

• User Manuals in English

OPTIONAL EQUIPMENT

• Linear Drive

• Dust Collection Unit

• Additional Operator Glasses

• Lens with 7.874” Focus Length

• Sheet loading & unloading systems

• Automation & Storage systems

• Automatic Nozzle Changer

• Custom table sizes

• Up to 6 kW laser laser light sources

• Light safety barrier

• Air conditioner for electrical panel

• Metalix, Almacam etc. CAD/CAM software

• LCM (laser cut monitor) sensor for pierce detection and cut loss control

CUTTING HEAD

• The laser beam is delivered to the cutting head by fiber optic cable.

• The fiber optic cable is fixed to the input of cutting head.

• The laser is delivered to the focusing unit after being aligned in the collimator.

• The laser beam is set to desired focus using the lenses in the focusing unit.

• The protection glass protects the lenses from the particles which are caused by the cutting operation.

• The sensor insert is part of the elevation control system and helps to adjust the distance between material and cutting head.

• Elevation control is checked with the most precise sensors in the market. This helps to produce better cuts.

• The main function of the ceramic is to protect the cutting head.

• The nozzle is used to control the assist gases. It is also a part of the capacitive control system.

Configuration of Laser cutting machine

Mechanical platform: the cover, rails, base, composed of reflective frames and other mechanical parts;

Drivetrain: four balanced by the three imported high-precision linear guide, three high-precision ball screw, belt, three stepper motors and several gears;

Auxiliary systems: There are circulating cooling water pump, blowing compressors, smokeexhaust fan;

Optical system: a laser tube, laser power supply, three metal reflection mirrors and a focusing head component.

Advantages

1) Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.

2) High cutting speed: Cutting speed is more than 20m/min

3) Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

4) High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber optic laser cut has three times photoelectric conversion efficiency

5) Low cost & Low main tenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;

6) Easy operations: fiber line transmission, no adjustment of optical path;

7) Super flexible optical effects: Compact design, easy to flexible manufacturing requirements.

Techincal Parameter

Model	ECO-FIBER 3015 / 6KW
CNC Control Unit	FAGOR 8060 CNC System
X axis (Rack & Pinion)	3000 mm
Y axis (Rack & Pinion)	1500 mm
Z axis (Ball Screw)	100 mm
Maximum cutting capacity	Mild stee	32 mm
	Stainless steel	16 mm
	Aluminyum	16 mm
Work piece dimensions	1525 x 3050 mm
Rapid traverse (X and Y axis)	105 m/min
Acceleration	2.5G (25m/s2)
Vector speed	148 m/min
Absolute positioning accuracy	± 0.08 mm
Repeatability (X and Y axis)	± 0.03 mm
Max. load capacity	2450 kg
High Performance CNC System	FAGOR 8060 from Spain Brand
Laser power	IPG YLS-6 kW from Germany
High Performance Servo motor/drive	FAGOR from Spain Brand
Laser Cutting Head	PRECITEC from Germany
Motoreducer	STOBER from Germany
