table model cnc plasma cut machine 5 axis cnc plasma cutting machine

5 axis plasma cutting machine

Brief introduction

This machine adopts integrated design as well as a combination of CNC,mechanical transmission and thermal cutting.That makes it to be a high technology ,high precision and high reliability cutting machine.Excellent human interface guarantees the easy operating and quick processing forvarious workpiece.

Quick Details

Condition: New
Voltage: 220V/380V
Rated Power: 8.5KW
Dimension(L*W*H): 1300*2500mm
Weight: 1500kg
Certification: CE ISO
Warranty: 1 Year
After-sales Service Provided: Engineers available to service machinery overseas
Cutting wadth: 300-2000mm
Cutting length: 2500-6000mm
Numerical control system: Beijing Start /Starfire or customized
Cutting thickness: depended on plasma power
Max moving speed: 20000mm/min
Cutting speed: depended on workpiece thickness
Working table: dust collecting
Input power: 8.5KW
File transfer: USB interface
Working mode: Untouched arc striking Shandong Supplier

Technical parameters

Name	cnc plasma cut machine
Working area	1300*2500mm
Cutting thickness	depended on plasma power
Max moving speed	20000mm/min
Plasma power	60A or 100A
Drive motor	Step motor
Control system	Beijing Start /Starfire or customized
Working voltage	220V/380V
Package	plywood case
Cutting material	titanium,aluminium,tube and so on

Features

(1)Less and tidy incision ,no cutting slag or need of after treatment .

(2)High accuracy rack gear transmission. Lower noise, stable and accurate coordinate movement.

(3)Adopting swift clamp to aviod workpiece moving and greatly reduce the cost .

FAQ

1), Q: Do you have after sales support?

A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.

2),Q: I am not sure if this machine suitable for my work?

A: Don't worry, just tell me your working materials, max working area and cutting thickness, then I will recommend you the most suitable machine for you.

3),Q: Are you factory or trading company?

A: We are factory, which manufactures CNC cutting machines , with 10 years experience in CNC machine’s industry.

4),Q:What other things also need after we bought your machines?

A:With plasma cutting: need plasma power source and air compressor. You can match plasma power supply by yourself, or buy together with the cutter from us, it's optional.
If you buy from us, we will connect the wires of plasma power source and CNC cutting machine together, then more conveniently to use.

5),Q:How can i do if the machine goes wrong?

A:If confronted with such problems,online service is offered,you could contact our sales. Also,we offer engineer delivery service.Please contact us asap and don’t try fix the machine by yourself or someone else.We will response within 12 hours as quick as we can to solve it for you.
